Channel resolution：>80dB；
SO：>105dB；
Switching rate： 40v/us；
damping factor 1khz@8ohm：>400:1;
input sensitivity: 0.7v/1v/1.4v switchable;
input impedance: 20k ohm balance;
+86–21–61478548
wechat
Product DetailsMODEL | CK-2250 | CK-2350 | CK-2450 | CK-2600 | CK-2800 | CK-21000 | CK-21200 |
OUTPUT POWER(8OHM) | 250Wx2 | 350Wx2 | 450Wx2 | 600Wx2 | 800Wx2 | 1000Wx2 | 1200Wx2 |
OUTPUT POWER(4OHM) | 400Wx2 | 550Wx2 | 900Wx2 | 1100Wx2 | 1300Wx2 | 1500Wx2 | 1800Wx2 |
Frequency response | 15Hz-25kHz(+0/-1dB) | ||||||
THD | <0.03% | ||||||
Voltage Gain | 26dB | 28dB | 30dB | 32dB | 34dB | 35dB | 38dB |
Channel resolution | >80dB | ||||||
SO | >105dB | ||||||
Switching rate | 40v/us | ||||||
damping factor 1khz@8ohm | >400:1 | ||||||
input sensitivity | 0.7v/1v/1.4v switchable | ||||||
input impedance | 20k ohm balance | ||||||
OUPUT CIRCUIT | class AB | class AB | class AB | class H | class H | class H | class H |
protection circuit design | DC, ultra high frequency, short circuit, overloading, turn on/ turn off delay, overheat protection | ||||||
LED indicator | power indicator, signal level indicator, distortion indicator, protection indicator | ||||||
power consumption | 500W | 700W | 1000W | 1200W | 1600W | 2000W | 2400W |
WEIGHT | 12KG | 16KG | 18KG | 20KG | 22KG | 25KG | 28KG |
DIMENSION | 485X450X85CM | ||||||
