S/N Ratio: ≥100dB;
Frequency Response: 5Hz -20KHz(+-1dB);
Damping Factor: >500;
THD: <0.05%;
Switch Rate: 28V/us;
input sensitivity: 23dB 26dB 29dB 32dB 35dB 38dB 41dB 44dB;
+86–21–61478548
wechat
Product DetailsTechnical Parameter | G-2.8 | G-2.13 |
Power Output(2ohm) | 2X2030W/2OHM | 2X3300W/2OHM |
Power Output(4ohm) | 2X1450W/4OHM | 2X2350W/4OHM |
Power Output(8ohm) | 2X800W/8OHM | 2X1300W/8OHM |
Bridge(4ohm) | 1X4000W | 1X6600W |
Bridge(8ohm) | 1X2800W | 1X4700W |
S/N Ratio | ≥100dB | |
Frequency Response | 5Hz -20KHz(+-1dB) | |
Damping Factor | >500 | |
THD | <0.05% | |
Switch Rate | 28V/us | |
input sensitivity | 23dB 26dB 29dB 32dB 35dB 38dB 41dB 44dB | |
input impedance | (Balanced)20KHZ ohm (Unbalanced)10KHZ ohm | |
Voltage Gain(8ohm) | 40dB | |
Output circuitry | Class D | |
Cooling | FAN | |
Power supply | AC90V-264V(50HZ-60HZ) | |
product Size | 483mmX300mmX88mm | |
Package Size | 483mmX300mmX88mm | |
G.W. | 6.3kg | 7.3kg |
