Power Output(2ohm): 2X2030W/2OHM;
Power Output(4ohm): 2X1450W/4OHM;
Power Output(8ohm): 2X800W/8OHM;
Bridge(4ohm): 1X4000W;
Bridge(8ohm): 1X2800W;
S/N Ratio: ≥100dB;
+86–21–61478548
wechat
Product DetailsNew DSP GaN technology Digital Power AMP | |
Power Output(2ohm) | 2X2030W/2OHM |
Power Output(4ohm) | 2X1450W/4OHM |
Power Output(8ohm) | 2X800W/8OHM |
Bridge(4ohm) | 1X4000W |
Bridge(8ohm) | 1X2800W |
S/N Ratio | ≥100dB |
Frequency Response | 5Hz -20KHz(+-1dB) |
Damping Factor | >500 |
THD | <0.05% |
Switch Rate | 28V/us |
input sensitivity | 23dB 26dB 29dB 32dB 35dB 38dB 41dB 44dB |
input impedance | (Balanced)20KHZ ohm (Unbalanced)10KHZ ohm |
Voltage Gain(8ohm) | 40dB |
Output circuitry | Class D |
DSP Process | 1 xAKM7735 DSP |
EQ TYPE | 7 CH EQ, LOW PASS Filter;High Pass Filter; PEQ; |
EQ | -12dB ~+12dB |
Cooling | FAN |
Power supply | AC90V-264V(50HZ-60HZ) |
Product Size | 483mmX300mmX88mm |
Package Size | 483mmX300mmX88mm |
G.W. | 6.3kg |
