12/16 Line channel
6/10 MIC
24 DSP
3-Band/4-Band EQ
+86–21–61478548
wechat
Product DetailsModel | NP12X-USB | NP16X-USB |
Input | 6 MIC Input | 10 MIC Input |
6 MONO/Stereo LINE Input | 10 MONO/Stereo LINE Input | |
4 Group Stereo Input | 4 Group Stereo Input | |
Output | 2 CH MAIN STEREO Output | 2 CH MAIN STEREO Output |
2 CH AUX Output | 4 CH AUX Output | |
2 GROUP Output | 4 GROUP Output | |
1 GROUP Stereo Output | 1 GROUP Stereo Output | |
1 CH HEADPHONE Output | 1 CH HEADPHONE Output | |
1 CH FOOT SWITCH | 1 CH FOOT SWITCH | |
Power Supply | 110-220V, 30W | 110-220V, 30W |
Feature | * with Bluetooth/MP3/Recording/USB Sound Card /USB Recording & LCD display | |
* 48V phantom supply on Mic connectors | ||
* Low-cut switch/Attenuation/Peak indicator on all Mic input channels | ||
* Built-in 24 bits DSP | ||
* 3-band EQ on MONO input channels, 2-band EQ on STEREO input channels | * 4-band EQ on MONO input channels, 3-band EQ on STEREO input channels | |
* Power amplifier with limiter | ||
* OTG | ||
Dimensions | 305*405*160mm | 445*480*160mm |
Weight | 5.1kg | 7.8kg |
