8/12 Line channel
Dual 99 DSP
4-Band EQ
2 CH Group Output
7 Group EQ
+86–21–61478548
wechat
Product DetailsModel | HERO 8 | HERO 12 |
Input | 6 MIC Input | 10 MIC Input |
6 MONO/Stereo LINE Input | 8 MONO/Stereo LINE Input | |
2 Group Stereo Input | 2 Group Stereo Input | |
Output | 2 CH MAIN STEREO Output | 2 CH MAIN STEREO Output |
3 CH AUX Output | 3 CH AUX Output | |
2 GROUP Output | 2 GROUP Output | |
1 GROUP Stereo Output | 1 GROUP Stereo Output | |
1 Track CD/TAPE Output | 1 Track CD/TAPE Output | |
1 CH HEADPHONE Output | 1 CH HEADPHONE Output | |
1 CH FOOT SWITCH | ||
Power Supply | 110-220V, 30W | 110-220V, 30W |
Feature | * with Bluetooth/MP3/Recording/USB Sound Card /USB Recording & LCD display * 48V phantom supply on Mic connectors * Low-cut switch on all Mic input channels * Built-in dual DSP with 99 effects * 4-band EQ on MONO input channels, 3-band EQ on STEREO input channels * Built-in 7-band Stereo equalizer * 7-band Group Stereo equalizer * Peak indicator * OTG | |
Dimensions | 370*425*85mm | 485*425*85mm |
Weight | 4.15kg | 5.35kg |
