Phantom Power Voltage：+48V
Power Requirements：AC 110 – 240 V, 50 / 60 Hz；
Output Power：2x220W/4ohm, 2x120W/8ohm；
Features：USB, Bluetooth, Computer Sound Card, Radio, Recording；
+86–21–61478548
wechat
Product DetailsModel | DM40 | DM60 | DM80 | |
Input channels | Mono: MIC/LINE | 3 | 5 | 7 |
Stereo: LINE | 1 | 1 | 1 | |
Output Channels | Stereo out | 2 | 2 | 2 |
Phones | 1 | 1 | 1 | |
AUX SEND | 1 | 1 | 1 | |
Input Channel Function | EQ | HIGH: Gain: +15 dB, Frequency: 10 KHz shelving | ||
MID: Gain: +15dB/-15dB Frequency: 2.5KHz peaking | MID: Gain: +15dB/-15dB Frequency: Mono 2.5KHz peaking | |||
LOW: Gain: +15dB/-15dB, Frequency: 100 Hz shelving | ||||
PEAK LED | LED turns on when post EQ signal reaches 3 dB below clipping level | |||
Level Meter | Pre Monitor Level | 2 x 12 + Segment LED meter(PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30 dB] | ||
Built-in Effect | SPX Algorithm | 32 programs, PARAMETER control: | ||
USB Audio | 2 IN / 2 OUT | USB Audio Class 2.0 compliant, Sampling Frequency:Max 192 kHz, Bit Depth: 24-bit | ||
Phantom Power Voltage | +48V | |||
Power Requirements | AC 110 – 240 V, 50 / 60 Hz | |||
Output Power | 2x220W/4ohm, 2x120W/8ohm | |||
Features | USB, Bluetooth, Computer Sound Card, Radio, Recording | |||
