STE-60/120/180/250/350/500/650(B)(BC)_Qianxin Electronics Co., Ltd.

· 3 Mic inputs, 2 Line inputs and 1 line output;

· Mic1 input and chime button on front panel with priority-function;

· Mic2 and Mic3 channels with echo effector;

· Built-in MP3 player with Bluetooth and FM radio;

· Main volume control, treble and bass adjusters;

· 5 segments signal level indication, fault and clip indication;

+86–21–61478548

wechat

POWER OUTPUT:

STE-60(B)(BC): 60W;

STE-120(B)(BC): 120W;

STE-180(B)(BC): 180W;

STE-250(B)(BC): 250W;

STE-350(B)(BC): 350W;

STE-500(B)(BC): 500W;

STE-650(B)(BC): 650W;

· 3 Mic inputs, 2 Line inputs and 1 line output;

· Mic1 input and chime button on front panel with priority-function;

· Mic2 and Mic3 channels with echo effector;

· Built-in MP3 player with Bluetooth and FM radio;

· Main volume control, treble and bass adjusters;

· 5 segments signal level indication, fault and clip indication;

· Protection: turn on delay, over current, over heat, short circuit;

· B series with 6 zone outputs and separate zoning switch;

· BC series with 6 zone outputs and separate zoning volume controls;

· Fan cooling control;

· Output: 100V,70V, 4~16 ohm;

· Power supply: AC115V/230V;
