Connectors:
2x XLR/TRS Combo Jack Input;
1x Stereo RCA Input;
1x Wireless Bluetooth Audio Input;
1x XLR THRU Output;
+86–21–61478548
wechat
Product DetailsModel: | SC803 | SC1003 | SC1203 | SC1503 |
Size: | 8” | 10" | 12" | 15" |
Frequency response (-3 dB): | 42Hz-20KHz | 42Hz-20KHz | 40Hz-20KHz | 30Hz-20KHz |
Low frequency design: | 8"band-pass | 10"band-pass | 12"band-pass | 15"band-pass |
Mid-high design: | 6x2.3 Neodymium full range speake | 8x3.5 Neodymium full range speake | ||
LF Driver: | 8"with 25mm coil | 10" with 38mm coil | 12" with 51mm coil | 15" with 65mm coil |
HF Driver: | 2. 3" VC full range | 3.5" VC full range | ||
Maximum SPL: | 122dB | 126dB | 128dB | 130dB |
Coverage (H x V): | 100°X40° | 140°X40° | 160°X40° | |
Amplifier rating | 600W | 1000W | 1200W | 1200W |
LF channel rating | 300W | 500W | 600W | 600W |
HF channel rating | 300W | 500W | 600W | 600W |
Crossover frequency: | 4th/200hz DSP | |||
Connectors: | 2x XLR/TRS Combo Jack Input 1x Stereo RCA Input 1x Wireless Bluetooth Audio Input 1x XLR THRU Output | |||
Enclosure: | Sub:12 m MDF Column: 12 mm NDF Pole: Aluminum | Sub: 15 mm plywood Column: 9 mm plywood Pole: Aluminum | ||
Grille: | Steel with black or white powder coat | |||
Color: | Black or white | |||
Dimensions(WxHxD): | SUB W258 H517 D330 | SUB 315 H625 D410 | SUB 365 H625 D450 | SUB 350 H710 D500 |
Column W96 H472 D103 Pole W35 H800 D50mm Total height H1595mm | Column W103 H808 D180 Pole W35 H800 D50mm Total height H2000mm | Column W103 H808 D180 Total height H2150mm | ||
Net weight: | SUB :10KG | SUB:15.5KG | SUB: 19.5KG | SUB: 25.5KG |
Column: 2.1KG | Column:5.2KG | |||
Pole: 0.9KG | ||||
Shipping weight: | 14.4kg | 23.6kg | 29.9kg | 39.8kg |
Shipping Dimensions (HxWxD): | W540 H570 D355mm | W520 H890 D500mm | W580 H890 D540mm | W708 H860 D430mm |
power consumption | 100-240V AC,50-60 Hz,1.5-0.6 A | |||
