Loading Rating: 20W / 30W / 40W;
Frequency range: 70Hz-20KHz / 50Hz-20KHz / 40Hz-20KHz;
SPL(@1W/m): 88dB / 90dB / 92dB;
Tweeter: 1/2" Mylar;
Material, Color: AMS, White;
+86–21–61478548
wechat
Product DetailsTechnical Data | HSR190-5T developing | HSR190-6T | HSR190-8T developing |
Loading Rating | 20W | 30W | 40W |
Transformer tapping | 20W-10W-5W(100V) 20W-10W-5W-2.5W(70V)， | 30W-15W-7.5W(100V), 30W-15W-7.5W-3.75W(70V) | 40W-20W-10W(100V), 40W-20W-10W-5W(70V) |
Frequency range | 70Hz-20KHz | 50Hz-20KHz | 40Hz-20KHz |
SPL(@1W/m) | 88dB | 90dB | 92dB |
Woofer and lmpedance | 5 1/4" and 8 ohms | 6 1/2" and 8 ohms | 8" and 8 ohms |
Tweeter | 1/2" Mylar | 1/2" Mylar | 1/2" Mylar |
Material, Color | AMS, White | AMS, White | AMS. White |
